| Properties | Unit | JZ-E1 | JZ-E2 |
|---|---|---|---|
| Diameter | mm | 3-5 | 2.5-4 |
| Surface Area | ≥m2/g | 280 | 285 |
| Pore Volume | ≥ml/g | 0.38 | 0.38 |
| Crush Strength | ≥N/Pc | 150 | 150 |
| Bulk Density | ≥g/ml | 0.70 | 8 |
| Abrasion rate | ≤ | 0.3 | 0.3 |
| Static water adsorption | ≥ | 18 | 19 |
| Dynamic adsorption rate | ≥ | 14 | 15 |
25 kg/Valve pocket
150 kg/steel drum
The product as desiccant cannot be exposed in the open air and should be stored in dry condition with air-proof package.
JZ-E activated alumina is a composite material specifically researched and developed for use in compression heat models. In comparison to other forms of alumina, it exhibits lower and more consistent outlet pressure dew points for finished gas under identical inlet pressure dew point and temperature conditions. As a result, JZ-E activated alumina is better suited for use in compression heat dryers.
JZ-E activated alumina is a composite material specifically developed for air dryers, air separation systems, and compression heat models.
The JZ-E1 model features a diameter of 3-5 mm, while the JZ-E2 model features a slightly smaller diameter of 2.5-4 mm.
The product is supplied in either 25 kg/Valve pockets or 150 kg/steel drums.
As a desiccant, it must not be exposed to the open air. It should be kept in dry conditions within an air-proof package.
Compared to other alumina forms, it exhibits lower and more consistent outlet pressure dew points for finished gas under the exact same inlet pressure dew points and temperature conditions.
